New Tri-axle 40 feet Flatbed truck trailer
Designed to handle a wide range of cargoes, our flatbed semi-trailer is a versatile and efficient cargo transportation model that offers a spacious, open platform for easy loading and unloading. It also has a sturdy structure and solid frame to ensure the safe transportation of various oversized and irregularly shaped items, such as machinery, construction materials and containers. It allows flexible arrangement of cargo and effective use of space. Experience the convenience and reliability of our flatbed semi-trailers, which are tailored for industries that need to transport large cargo quickly and efficiently. Maximize productivity and streamline logistics with our trusted and versatile cargo transport solutions.
| Use | Truck Trailer |
| Type | Semi-Trailer |
| Material | Steel |
| Size | 12500*2500* 1550 |
| Max Payload | 30-60 tons |
| Place of Origin | Shandong, China |
| Product name | Flatbed truck trailer |
| Loading capacity | 30-50 tons |
| Usage | Transport 2 units 20ft containers or 40ft container |
| Tare weight | 7.5 tons |
| Axle brand | 3*13 Ton Axle,FUWA brand |
| Tyre brand | 12 units 12.00R22.5 tires,Triangle brand |
| Rims | 6pcs*11.75-22.5 |
| Suspension System | 3 axle with spring suspension, ZY brand |
| Brake System | Dual line pneumatic brake systemT30/30 air chamber: parking brakeWABCO relay valve |
| Under Frame | Main Beam is height 500mm; Q345B steel14/16/8mm |
| Side beam | 16#U-steel |
| Kingpin | 2'or 3.5'(90mm) interchangeable |
| Landing Gear | 28tons heavy duty; 2 pieces |
| Platform | 3mm thick checkered plate |
| Front headboard | 1.5m high |
| Twist locks | 8 pies for 1x40ft container or 2x20ft containers |
| Electrical System | 1.Voltage: 24v 2.Receptacle: 7 ways(7 wire harness): German standard |
| Lights/Reflectors | LED; Rear light, rear reflector, turn indicative light, side reflector, fog lamp, number plate light |
| Painting | As your request |
| Spare Tyre Carrier | One piece |
PACKING AND SHIPPING
We find the best shipping solution according to the actual order size to reduce the transportation cost and save the transportation cost for customers Common shipping: bulk carrier, ro-ro ship,container ship, frame ship
(1) Waxing: carry out wax spraying treatment
(2) Packing: stabilized and fixed with steel wire to protect the trailer during transportation.
(3) Transportation: Reliable logistics services from well-known freight forwarding providers to make the transportation process safe and timely.
(4) In 80% of the cases, we can provide customers with 15-20 days delivery for regular trailers.
(5) We can ship all trucks and trailers and spare parts by all means of transportation.
(6) For 90% of our cargoes, we will ship by sea, by container or roll-on/roll-off/bulk/flatbed to all major continents, such as South America, the Middle East, Africa, Oceania, etc. We can also ship by road or by road to the neighboring countries of China, such as Russia, Tajikistan, Kazakhstan and Mongolia.
(7) For China's neighboring countries, such as Russia, Tajikistan, Kazakhstan, Mongolia, etc., we can ship by road or railroad transportation trucks.
(8) For light spare parts for urgent needs, we can ship them by international courier services, such as DHL, TNT, UPS or Fedex.
